| Specification | Elite 4kW |
|---|---|
| Rated Power | 4000VA / 4000W |
| Input Voltage | 230 VAC |
| Selectable Voltage Range | 170–280 VAC (For Personal Computers) |
| 90–280 VAC (For Home Appliances) | |
| Frequency Range | 50 Hz / 60 Hz (Auto sensing) |
| AC Voltage Regulation (Batt. Mode) | 230VAC ± 10% |
| Surge Power | 8000VA |
| Efficiency (Peak) | 93% |
| Transfer Time | 10 ms (For Personal Computers) |
| 20 ms (For Home Appliances) | |
| Waveform | Pure sine wave |
| Battery Voltage | 24 VDC |
| Floating Charge Voltage | 27 VDC |
| Overcharge Protection | 33 VDC |
| Solar Charger Type | MPPT |
| Maximum PV Array Power | 5000W |
| MPP Range @ Operating Voltage | 60–450 VDC |
| Maximum PV Array Open Circuit Voltage | 500 VDC |
| Maximum PV Input Current | 27A |
| Maximum Solar Charge Current | 120A |
| Maximum AC Charge Current | 100A |
| Maximum Charge Current | 120A |
| Dimension (D × W × H) | 115 × 300 × 435 mm |
| Net Weight | 9 kgs |
| Communication Interface | USB / RS232 / RS485 / WiFi / Dry-contact |
| Humidity | 5% to 95% Relative Humidity (Non-condensing) |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -15°C to 60°C |
