| Model | ||
| Model | SPARK 1.5K | |
| Rated Power | 1500VA/1500W | |
| Input | ||
| Voltage | 230 VAC | |
| Selectable Voltage Range | 170-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances) | |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) | |
| Output | ||
| AC Voltage Regulation (Batt. Mode) | 230VAC ± 5% | |
| Output Power | 1500W with PV & battery; 1200W with battery only |
|
| AC Output No. | Single | |
| Surge Power | 3000VA | |
| Efficiency (Peak) | 93% | |
| Transfer Time | 10 ms (For Personal Computers); 20 ms (For Home Appliances) | |
| Waveform | Pure sine wave | |
| Battery | ||
| Battery Voltage | 12 VDC | |
| Floating Charge Voltage | 13.5 VDC | |
| Overcharge Protection | 16 VDC | |
| Solar Charger & AC Charger | ||
| Solar Charger Type | MPPT | |
| Maximum PV Array Open Circuit Voltage | 350 VDC | |
| Maximum PV Array Power | 2000W | |
| Maximum PV Input Current | 13 A | |
| MPP Range @ Operating Voltage | 30 ~ 300 VDC (Min. 60VDC without battery connected) |
|
| Maximum Solar Charge Current | 100A | |
| Maximum AC Charge Current | 80A | |
| Maximum Charge Current | 100A | |
| Physical | ||
| Dimensions, D x W x H (mm) | 90 x 288 x 357 | |
| Net Weight (kgs) | 6.6 | |
| Communication Interface | RS232/RS485(BMS) | |
| Environment | ||
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | |
| Operating Temperature | -10°C to 50°C | |
| Storage Temperature | -15°C to 60°C | |
| Product specifications are subject to change without further notice. | ||
